Apollo 1120F 1200VA Plastic Body Offline UPS
Short Description
- Model: Apollo 1120F 1200VA
- Load Capacity: 1200VA
- Transfer Time: 2ms typical; 5ms maximum
- Waveform: PWM Simulated Sine wave
- 2 x Lead-Acid maintenance-free battery
- Brand: Apollo
Title
Title
Specification
| Basic Information | |
| Brand | Apollo |
| Model | 1120F |
| Product Type | Offline UPS |
| Capacity | 1200VA |
| Rated Load Capacity | 600W |
| Body Material | Plastic |
| Color | Black |
| Input Specifications | |
| Input Voltage | 230VAC |
| Input Voltage Range | 140–300VAC (published listing specification) |
| Input Frequency | 50/60Hz |
| Output Specifications | |
| Output Voltage | 220–230VAC ±10% |
| Output Frequency | 50/60Hz ±1% |
| Output Waveform | Simulated Sine Wave / PWM Simulated Sine Wave |
| Transfer Time | 2ms typical; up to 5ms maximum in some listings |
| Battery Information | |
| Battery Type | Lead-acid, maintenance-free |
| Battery Quantity | 2 |
| Battery Rating | 12V 7Ah or 12V 7.2Ah per battery, depending on listing |
| Total Battery Voltage | 24V DC |
| Backup Time | Approximately 5–15 minutes for typical PC loads; varies with load and battery condition |
| Protection & Features | |
| Built-in Stabilizer | Yes |
| Automatic Voltage Regulation | Boost and Buck AVR, as listed |
| Overload Protection | Yes |
| Short-Circuit Protection | Yes |
| High/Low Voltage Protection | Listed |
| Cold Start | Listed |
| Low-Battery Alarm | Listed |
| Overload Alarm | Listed |
| No-Load Auto Shutdown | Listed |
| LED Display | No, according to the four-port listing |
| Physical Information | |
| Output Ports | Verify actual version: 2-port, 3-port or 4-port |
| Cable Length | Approximately 1 metre |
| Dimensions | 115 × 360 × 160mm |
| Weight | Approximately 11.5kg, as listed by some sellers |
| Noise Level | Less than 40dB, as listed |
| Warranty | |
| Warranty Period | 1 year warranty |
Product Descriptions
Apollo 1120F 1200VA Plastic Body Offline UPS
The Apollo 1120F 1200VA Plastic Body Offline UPS is designed to provide backup power for desktop computers and other compatible electronic equipment during unexpected power interruptions. With a rated capacity of 1200VA, a 600W load capacity, dual batteries and a built-in stabilizer, this UPS is suitable for home and office computer setups. It helps users save ongoing work and shut down their systems properly when the main power supply fails.
The Apollo 1120F 1200VA Plastic Body Offline UPS provides backup power for compatible desktop computers and essential electronic devices during power interruptions. With 1200VA capacity, 600W load capacity, dual 12V 7.2Ah batteries and a built-in stabilizer, it is suitable for home and office computer setups. Actual backup time depends on connected equipment and battery condition.
1200VA Capacity with 600W Load Support
The Apollo 1120F offers a 1200VA capacity and supports a maximum specified load of 600W. It is suitable for compatible desktop PCs, monitors and other equipment within its rated power limit. Check the actual power consumption of your connected devices before use.
Dual Battery Backup System
This model is listed with two 12V 7.2Ah batteries, providing backup power when the mains supply is interrupted. Actual backup duration varies according to connected load, battery age, battery condition and operating environment.
Built-in Voltage Stabilizer
The built-in stabilizer helps regulate voltage fluctuations within the unit's supported operating range. This feature is useful for computer setups that experience variations in their incoming power supply.
Fast Transfer Time
The listed typical transfer time is approximately 2 milliseconds. The UPS switches to battery operation during a power interruption to help keep compatible connected equipment running.
Protection for Connected Equipment
The Apollo 1120F specification lists overload and short-circuit protection. These protective features help safeguard the UPS and connected equipment under specified fault conditions. Users should still use appropriate electrical grounding and surge protection where required.
Plastic Body with Multiple Output Ports
The UPS features a black plastic enclosure and, in the four-port version, provides four rear output connections for compatible devices. Its design is suitable for home desktops, office workstations and everyday computer setups.
Suitable for Home and Office PCs
The Apollo 1120F can be used with compatible desktop computers, monitors and other equipment whose combined power demand stays within the UPS rating. For gaming PCs or systems with power-hungry graphics cards, check actual power consumption carefully before choosing this model.
Buy Apollo 1120F UPS from Rose Tech & Computer
Rose Tech & Computer helps customers find computer power-backup solutions for home, office and desktop PC setups. Before purchasing the Apollo 1120F, verify the required load capacity, battery configuration, output-port version and current product availability.
Warranty: 1-year warranty, subject to the applicable seller warranty terms and required documentation.
