Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD M-ATX Gaming Motherboard

Gigabyte

  • Model: B650M AORUS ELITE AX
  • Supported CPU: Ryzen 7000 Series Processors for Socket AM5
  • Supported RAM: 4x DDR5, up to 128GB, 6666(OC)
  • Graphics Output: 1x Display Port, 1 x HDMI
  • Features: Realtek 2.5GbE LAN & AMD Wi-Fi 6E

Short Description

  • Regular Price: 32,670৳
  • Special Price: 29,400৳
  • Availability: In Stock
  • Brand: GIGABYTE
  • Product ID: 12072

29,400.00৳  32,670.00৳

Compare

Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD M-ATX Gaming Motherboard

Brands

Gigabyte

Model

B650M AORUS ELITE AX

Color

Black

Warranty

03 years warranty

Supported CPU AMD Socket AM5, support for AMD Ryzen 7000 Series Processors
Chipset AMD B650
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out
PCI CPU:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Chipset:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
Memory
Type DDR5
Slots 4 DIMMs
Supported Memory 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
Dual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
Maximum Memory 128GB
Graphics
Graphics Integrated Graphics Processor:
1 x DisplayPort, supporting a maximum resolution of 3840×2160@144 Hz
* Support for DisplayPort 1.4 version and HDR.
1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports.
Connector & Ports
HDMI 1x HDMI
Display Port (s) 1 x DisplayPort
USB (s) CPU:
1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
CPU + USB 2.0 Hub:
4 x USB 2.0/1.1 ports on the back panel
Chipset:
1 x USB Type-C port with USB 3.2 Gen 2×2 support, available through the internal USB header
3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
4 x USB 2.0/1.1 ports available through the internal USB headers
Chipset+USB 3.2 Gen 1 Hub:
4 x USB 3.2 Gen 1 ports on the back pane
LAN Port (s) Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0)
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
BLUETOOTH 5.2
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Intel Wi-Fi 6E AX210 (For PCB rev. 1.1)
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
BLUETOOTH 5.3
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Supported Storage CPU:
1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU)
* Actual support may vary by CPU.
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)
Chipset:
4 x SATA 6Gb/s connectors
RAID RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Audio 2 x Audio jacks
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x water cooling CPU fan header
3 x system fan headers
1 x system fan/water cooling pump header
2 x addressable LED strip headers
2 x RGB LED strip headers
1 x CPU cooler LED strip/RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C header, with USB 3.2 Gen 2×2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x THB_U4 add-in card connector
1 x reset button
1 x reset jumper
1 x Clear CMOS jumper
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Others
Special Features Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Bundled Software Norton Internet Security (OEM version)
LAN bandwidth management software

Description

Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD M-ATX Gaming Motherboard

The motherboard you mentioned, “Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD M-ATX Gaming Motherboard,” is not a valid model. As of my knowledge cutoff in September 2021, Gigabyte does not offer a B650M AORUS motherboard with DDR5 and AMD support.

The Gigabyte B650M AORUS ELITE AX is an AMD motherboard designed for M-ATX (Micro-ATX) form factor. It features support for DDR5 memory and comes with built-in Wi-Fi 6E connectivity, offering high-speed wireless networking capabilities. The motherboard is likely based on the Intel B650 chipset, which is designed for AMD Ryzen processors.

Being a gaming motherboard, it may offer various features targeted toward gaming enthusiasts, such as enhanced audio, multiple PCIe slots for graphics cards or expansion cards, and robust power delivery to support overclocking.

Please keep in mind that the information provided is based on the details you provided and may not reflect the actual specifications of any existing product. To get accurate and up-to-date information about Gigabyte’s motherboard offerings, I recommend visiting their official website or contacting their customer support. The GIGABYTE B650M AORUS ELITE AX Motherboard comes with 3 years of warranty.
