Brand | Gigabyte |
---|---|
Model | UD750GM 750W |
Color | Black |
Warranty | 05 years warranty |
Efficiency (Approx.) | 90% at typical load | |
Certification | 80 PLUS Gold | |
Fan Size | 120mm Hydraulic Bearing ( HYB ) fan | |
Voltage | 100-240 Vac (full range) | |
Frequency Range | 60-50 Hz | |
Current | 12-6 A | |
Modular Type | Fully Modular | |
Total Power | 750Watts | |
Main Power | ATX/MB 20+4 Pin x 1 : 610mm*1 | |
CPU | CPU/EPS 4+4 Pin x 2 : 600mm*2 | |
PCI-E | PCI-e 6+2 Pin x 4 : 600mm+150mm*2 | |
SATA | SATA x 8 : 600mm+150mm+150mm+150mm*2 | |
Floppy | 4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1 | |
Description
GIGABYTE UD750GM 750W Ultra Durable 80 Plus Gold Full Modular Power Supply
The GIGABYTE UD750GM 750W power supply features a wide range of high-quality materials and designs. Ultra Durable has high-quality Japanese primary capacitors, an improved thermal solution, a 120mm smart hydraulic bearing (HYB) fan, and six circuit safety designs. It provides users with a high-quality, reliable power source that may be utilized for an extended period. The primary capacitors are made of high-quality Japanese capacitors to ensure efficient performance and long-term durability. In comparison to the standard thermal solution, we increased the heatsink size by 200% or more and optimized the airflow. The heat dissipation performance is improved by more than 10%, extending the component’s service life. When the system is idle or under a low load (less than 20% load), the fan speed is automatically regulated and ceases. The hydraulic bearing fan has a longer and more reliable life cycle. The GIGABYTE UD750GM 750W Ultra Durable 80 plus Gold Full Modular Power Supply comes with a 05-Year Warranty.
