Cooler Master Masterbox TD500 Mesh White ATX Mid Tower Casing #MCB-D500D-WGNN-S01

Cooler Master

  • Model: Masterbox TD500 Mesh White
  • Polygonal Mesh+Triple ARGB Fans
  • Versatile Cooling Options
  • Dual 360mm Radiator Support

Short Description

  • Regular Price: 9,200৳
  • Special Price: 8,100৳
  • Availability: In Stock
  • Brand: Cooler Master
  • Part No: MCB-D500D-WGNN-S01

8,100৳  9,200৳


Cooler Master Masterbox TD500 Mesh White ATX Mid Tower Casing


Cooler Master


Masterbox TD500 Mesh White



Type Mid Tower
Tempered Glass Panel Yes
Motherboard Support Mini ITX, Micro ATX, ATX
E-ATX (support for up to 12″ x 10.7″)
External Features
Color(s) White
Weight 6.95 kg
Dimensions 493 x 217 x 469mm
Front Ports 2x USB 3.2 Gen 1 (formerly USB 3.0)
1x 3.5mm Audio Jack
1x 3.5mm Mic Jack
Expansion Slots 7
Radiator Support RADIATOR SUPPORT – TOP: 120mm, 240mm, 360mm, (44mm max motherboard component height)
RADIATOR SUPPORT – FRONT: 120mm, 140mm, 240mm, 280mm, 360mm
Fan Support FAN SUPPORT – TOP: 3x 120mm, 2x 140mm
FAN SUPPORT – FRONT: 3x 120mm, 2x 140mm
FAN SUPPORT – REAR: 1x 120mm
Pre- Installed Fans 3x 120mm ARGB Fans
Drive Bays 2.5″ / 3.5″ DRIVE BAYS: 2
2.5″ DRIVE BAYS: 2
I/O Port 2x USB 3.2 Gen 1 (formerly USB 3.0)
1x 3.5mm Audio Jack
1x 3.5mm Mic Jack
1x ARGB Controller
1x ARGB 2-to-3 splitter
Additional Feature
PSU 180mm
295mm (HDD cage removed)
Side Panel Tempered Glass
Clearance Space
Maximum Processor Cooler Height 165mm
Maximum Graphics Card Length 410mm



Display your build with the white MasterBox TD500 Mesh Mid-Tower Case from Cooler Master. Designed to look good without sacrificing functionality, this 40.14L mid-tower case comes with a tempered glass side window and three ARGB fans pre-installed. In addition to the pre-installed fans, users can add up to three 120mm fans or radiators to the top of the case, and an additional 120mm fan or radiator to the rear of the case. Inside, the TD500 can support ATX, Micro-ATX, Mini-ITX, and SSI CEB motherboards. It can also support E-ATX boards measuring up to 12″ by 10.7″.

Users also have plenty of room for storage, thanks to two 2.5/3.5″ drive bays, plus another four dedicated 2.5″ bays. The TD500 can also fit CPU coolers up to 6.49″ and graphics cards up to 16.1″. Bottom-mount ATX power supplies up to 7.08″ are supported by the case right out of the box, but users can fit large PSUs up to 11.61″ by removing the HDD cage. Behind the motherboard tray, a space for cable management provides 0.74″ of clearance, allowing you to keep unsightly wires from blocking your internals. Dominating the front of the case, a polygonal mesh is intended to facilitate better airflow along with dust filters on the top and bottom of the TD500. On top of the case, an I/O panel includes two USB 3.2 Gen 1 ports and separate 3.5mm ports for audio input and output. An ARGB controller and ARGB 2-to-3 splitter cable are also included, along with a hardware kit.

Polygonal Mesh

Featuring three-dimensional contours, the TD500’s polygonal mesh is designed to provide high airflow while also filtering dust.

USB 3.2 Gen 1

USB 3.2 Gen 1 features a maximum throughput of 5 Gb/s and is synonymous with USB 3.1 Gen 1 and USB 3.0.
